Newland HR42 Halibut HD Bluetooth

560,84 Incl. tax€463,51 Excl. tax In stock (6)
Unit price: €429,00 / Piece
The HR42 BT Halibut is part of Newland’s Pro series and is capable of reading high density barcodes, postal and DPM with ease. With a 1.8M drop rating, this cordless solution is ready to withstand tough environments. Read more
  • VAT is shifted after creating an account!
  • Would you like a quote? mail [email protected]
  • Stock items 1-3 working days delivery time!
  • Shipping throughout Europe and beyond!
  • Helps your business grow by integrating automation!
  • Your #1 RFID, IOT and AUTO-ID specialist!

Specifications

Brand:
Newland
Article number:
NLS-HR4280-BT-C(U)
Availability:
In stock (6)
Delivery time:
1-2 days

Information

HR42 Halibut HD Bluetooth

Handheld Scanners

The HR42 BT Halibut is part of Newland’s Pro series and is capable of reading high density barcodes, postal and DPM with ease. With a 1.8M drop rating, this cordless solution is ready to withstand tough environments.

HR42 product page banner

Features

Strong Wireless Connectivity.
The HR42 HD Halibut Bluetooth comes equipped with Bluetooth 5.0, giving you the freedom to scan barcodes up to 50 meters away from the cradle. Energy efficiency, quick data rate and easy pairing are just a few of the perks of this Bluetooth connection.

Extensive Capabilities.
In addition to excelling at scanning high density barcodes, the HR42 HD Halibut Bluetooth extends its data capture capabilities by also providing the added value of postal barcode decoding.

Superior Megapixel Performance.
Thanks to its 1280x960 pixel CMOS sensor, the HR42 HD Halibut Bluetooth easily captures high resolution images and brings the scanning performance to a whole new level.

Exceptional Aiming & Illumination.
Designed with the user in mind, the HR42 HD Halibut Bluetooth utilizes a highly visible laser aimer in order to achieve an accurate target. Along with the laser aiming capabilities, there is a flicker-free, soft white illumination to reduce fatigue during demanding activities.

IR Sensor.
Even when barcodes are presented 40cm away from the HR42 HD Halibut Bluetooth, the IR sensor is activated.

Rugged Industrial Construction.
Built for tough environments, the HR42 HD Halibut Bluetooth is built into an IP42 sealed and drop resistant (1.8M) housing.



Technical specifications

Performance
Memory Flash 900KB
Minimal Print Contrast 25%
Scan Angle Roll 360°
Scan Angle Pitch ±50°
Scan Angle Skew ±50°
Field of View Horizontal 40.5°
Field of View Vertical 30.4°
Motion Tolerance 2m/s
Data Capture
1D All major 1D symbologies, including EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey.
2D All major 2D symbologies, including PDF417, QR Code, Data Matrix, Aztec, Maxicode.
Image Sensor 1280×960 CMOS
Illumination White LED
Aiming 650nm laser diode
Scan Modes Automatic Batch, Manual Batch
Depth of Field EAN 13 (13mil) 25-155mm
Depth of Field Code 39 (5mil) 50-100mm
Depth of Field PDF417 (6.67mil) 40-105mm
Depth of Field Data Matrix (10mil) 40-110mm
Depth of Field QR (15mil) 35-155mm
Physical
Dimensions (mm) Scanner: 115.0(L)x74.0(W)x161.0(H)mm Cradle: 195.0(L)x82.5(W)x47.2(H)mm
Weight Scanner: 230g Cradle: 146g
Interfaces RS-232, USB
Battery Type 3200mAh lithium-ion battery
Expected Battery Life ≥ 14 hours of continuous operation, up to 30,000 scans per charge
Expected Charge Time 4 hours
Notifications Beep, LED indicator
Power Consumption 2160mW (typical)
Environmental
Operating Temperature -20℃ to 50℃ (-4°F to 122°F)
Storage Temperature -40℃ to 70℃ (-40°F to 158°F)
Humidity 5%~95% (non-condensing)
Electro Static Discharge (ESD) ±8 KV (direct discharge); ±16 KV (air discharge)
Drop 1.8m
IP Rating IP42
Wireless
Radio Technology 2.4 to 2.2835 GHz ISM Band, Bluetooth 5.0, BLE
Wireless Distance (max.) 30m (in open space)
Communication Modes Automatic Batch & Manual Batch modes
Software
Configuration Tools Nset
Certifications
Hardware FCC Part 15 Class B, CE EMC Class B
Warranty
Standard 3 years



Documents

Name View Type
 HR42 Halibut HD Bluetooth.pdf View Datasheet
 HR42 Halibut HD Bluetooth User Guide View User Guide
 Acuscan Brochure View PDF Brochure
 NSet View Software
 JPOS View Driver
 OPOS View Driver



Available versions

Partnumber Description
NLS-HR4280-BT-C(U) 2D CMOS Bluetooth Wireless Handheld Reader Mega Pixel, High Density (Blue surface) with Docking Station, USB cable and multi plug adapter.
