The ACS WalletMate II Boost Mobile Wallet NFC Reader Module (model ACM1552D-CW) enhances mobile applications with certified support for Apple VAS (ECP1.0), Apple ECP 2.0 Access Control, and Google Smart Tap protocols. It enables seamless contactless access for virtual passes such as loyalty cards, tickets, and IDs on iOS and Android devices.
Key Features
Fully certified for Apple VAS protocol (ECP1.0) and Apple ECP 2.0 Access Control.
Certified for the Google Smart Tap protocol.
Compatible with ISO 14443 Type A & B, MIFARE®, FeliCa, NFC ISO 18092, and ISO 15693 cards.
High-speed communication up to 848 kbps with mutual authentication and key diversification.
Compatibility and Connectivity
Supports USB 2.0 Full Speed interface and RS-232 (TTL/UART available on request), compliant with CCID and PC/SC standards. Operates in smart card reader/writer, card emulation, and keyboard emulation modes. Features user-controllable bi-color LED and buzzer for status indication. Includes USB cable; serial cable available optionally on request.
